BURNDY® YA34N | Connexion
BURNDY® YA34N 1092751

BURNDY®

1-Hole Copper Compression Lug

  • loading
  • Manufacturer: HUBBELL
  • Brand Name: BURNDY®
  • PN: YA34N
  • PN: YA34N
  • UPC: 78181001793
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Qty
  • loading

BURNDY® HYLUG™ 1-Hole Copper Compression Lug, Long Barrel, 1/0 AWG Conductor, 3/8 in Stud, Pink Color Code

  • Manufacturer: HUBBELL
  • Brand: BURNDY®
  • PN: YA34N
  • CX SKU: 1092751
  • UPC: 78181001793
  • Type: Compression Lug
  • Number of Holes: 1
  • Barrel Type: Long
  • Inspection Hole: No
  • Conductor Size: 1/0 AWG
  • Color Code: Pink
  • Die Code: 12
  • Stud Size : 3/8 in
  • Stud Hole Diameter : 0.56 in
  • Outside Diameter : 1.06 in
  • Barrel Length : 1.38 in
  • Pad Width : 0.75 in
  • Overall Length : 2.61 in
  • Hole Offset : 0.63 in
  • Pad Thickness : 0.12 in
  • Wire Strip Length : 1-7/16 in
  • Barrel Style : Chamfered
  • Tongue Angle : Straight
  • Voltage Rating : 600 VAC to 35 kV
  • pdfCatalog https://econtent.adhq.com/dam/Original/444/IDW_DOCUMENT_4875bfbbadaab779c1462033a529849d3a5fd64d178149b1220636dd5827744f.pdf
  • pdfLine Drawing https://econtent.adhq.com/dam/Original/445/IDW_DOCUMENT_66093e235408722d4e3295bb836d5ea5ce64a198d27de200fcb154f64f67e63d.pdf
  • pdfSpecification Sheet https://econtent.adhq.com/dam/Original/447/IDW_DOCUMENT_e128758b09d77ce46912f084f8587a54056a461098165f097fd291f37c69c439.pdf
