BURNDY® YA32N | Connexion
BURNDY® YA32N 1092748

BURNDY®

1-Hole Copper Compression Lug

  • loading
  • Manufacturer: HUBBELL
  • Brand Name: BURNDY®
  • PN: YA32N
  • PN: YA32N
  • UPC: 78181001890
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Qty
  • loading

BURNDY® HYLUG™ 1-Hole Copper Compression Lug, Long Barrel, 1/0 AWG Conductor, 3/8 in Stud, Pink Color Code

  • Manufacturer: HUBBELL
  • Brand: BURNDY®
  • PN: YA32N
  • CX SKU: 1092748
  • UPC: 78181001890
  • Type: Compression Lug
  • Number of Holes: 1
  • Barrel Type: Long
  • Inspection Hole: No
  • Conductor Size: 1/0 AWG
  • Color Code: Pink
  • Die Code: 12
  • Stud Size : 3/8 in
  • Stud Hole Diameter : 0.56 in
  • Outside Diameter : 0.95 in
  • Barrel Length : 1.38 in
  • Pad Width : 0.75 in
  • Overall Length : 2.61 in
  • Hole Offset : 0.63 in
  • Pad Thickness : 0.12 in
  • Wire Strip Length : 1-7/16 in
  • Barrel Style : Chamfered
  • Tongue Angle : Straight
  • Voltage Rating : 600 VAC to 35 kV
  • pdfLine Drawing https://econtent.adhq.com/dam/Original/445/IDW_DOCUMENT_66093e235408722d4e3295bb836d5ea5ce64a198d27de200fcb154f64f67e63d.pdf
  • pdfSpecification Sheet https://econtent.adhq.com/dam/Original/673/IDW_DOCUMENT_0798ff43f542dce1e48ce061421fdaf28d1b29666daf222a569f37de02da9b8b.pdf
  • pdfCatalog https://econtent.adhq.com/dam/Original/675/IDW_DOCUMENT_76d8df04ccf2300bda729f2386bcf59e2c74d8bdf4fcfa9a04124c632f71e9da.pdf
