BURNDY® HYLUG™ 1-Hole Copper Compression Lug, Long Barrel, 1/0 AWG Conductor, 3/8 in Stud, Pink Color Code
Burndy's 1-hole long barrel compression lug is copper, tin plated and is coded for copper conductors.
-
Manufacturer: HUBBELL
-
Brand: BURNDY®
-
PN: YA31
-
CX SKU: 1092747
-
UPC: 78181050495
- Type: Compression Lug
- Number of Holes: 1
- Barrel Type: Long
- Inspection Hole: No
- Conductor Size: 1/0 AWG
- Color Code: Pink
- Die Code: 12
- Stud Size : 3/8 in
- Stud Hole Diameter : 0.53 in
- Outside Diameter : 0.88 in
- Barrel Length : 1.38 in
- Pad Width : 0.75 in
- Overall Length : 2.61 in
- Hole Offset : 0.53 in
- Pad Thickness : 0.12 in
- Wire Strip Length : 1-7/16 in
- Barrel Style : Chamfered
- Tongue Angle : Straight
- Voltage Rating : 600 VAC to 35 kV
|
-
Catalog
https://econtent.adhq.com/dam/Original/684/IDW_DOCUMENT_6cddd247692aa19552cf4325d9299b89f1097478758346dbbe812cb5a0635a99.pdf
-
Specification Sheet
https://econtent.adhq.com/dam/Original/684/IDW_DOCUMENT_6f66113f4b60ea4b567366b141b16bdd07c5a744400ddd06f97b890381064aab.pdf
-
Line Drawing
https://econtent.adhq.com/dam/Original/685/IDW_DOCUMENT_79420c993db001d4c033590b8ab355cedfc14201ac93bcf928f0cfd54f6a69f8.pdf
