BURNDY® YAZ28TC12 | Connexion
BURNDY® YAZ28TC12 1092772

BURNDY®

1-Hole Copper Compression Lug

  • loading
  • Manufacturer: HUBBELL
  • Brand Name: BURNDY®
  • PN: YAZ28TC12
  • PN: YAZ28TC12
  • UPC: 78181023318
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Qty
  • loading

BURNDY® HYLUG™ 1-Hole Copper Compression Lug with Inspection Hole, Long Barrel, 2 AWG Conductor, 5/16 in Stud, Brown Color Code

  • Manufacturer: HUBBELL
  • Brand: BURNDY®
  • PN: YAZ28TC12
  • CX SKU: 1092772
  • UPC: 78181023318
  • Type: Compression Lug
  • Number of Holes: 1
  • Barrel Type: Long
  • Inspection Hole: Yes
  • Conductor Size: 2 AWG
  • Color Code: Brown
  • Die Code: 10
  • Stud Size : 5/16 in
  • Stud Hole Diameter : 0.52 in
  • Outside Diameter : 0.69 in
  • Barrel Length : 1.25 in
  • Pad Width : 1.02 in
  • Overall Length : 2.27 in
  • Hole Offset : 0.53 in
  • Pad Thickness : 0.14 in
  • Wire Strip Length : 1-5/16 in
  • Barrel Style : Chamfered/Skived
  • Tongue Angle : Straight
  • Voltage Rating : 600 VAC to 35 kV
  • pdfLine Drawing https://econtent.adhq.com/dam/Original/535/IDW_DOCUMENT_e17bf25afaefffd475df2d84706afde28b03232d8c433e7a2101d5f2e7a470d6.pdf
  • pdfCatalog https://econtent.adhq.com/dam/Original/804/IDW_DOCUMENT_682af1abe128e434ab78768ce2b33674e19a5bc66e1c8c5d525c709d81908b9b.pdf
  • pdfSpecification Sheet https://econtent.adhq.com/dam/Original/805/IDW_DOCUMENT_bfeafeeb9bfc8217d6484a6a17d5c7d169ba1a6b2d4aa3481c99fde1f3965bcd.pdf
