BURNDY® HYLUG™ 1-Hole Copper Compression Lug, Long Barrel, 1/0 AWG Conductor, 3/8 in Stud, Pink Color Code
Burndy's 1-hole long barrel compression lug is copper, tin plated and is coded for copper conductors.
-
Manufacturer: HUBBELL
-
Brand: BURNDY®
-
PN: YA26
-
CX SKU: 1092726
-
UPC: 78181050260
- Type: Compression Lug
- Number of Holes: 1
- Barrel Type: Long
- Inspection Hole: No
- Conductor Size: 1/0 AWG
- Color Code: Pink
- Die Code: 12
- Stud Size : 3/8 in
- Stud Hole Diameter : 0.40 in
- Outside Diameter : 0.56 in
- Barrel Length : 1.38 in
- Pad Width : 0.75 in
- Overall Length : 2.61 in
- Hole Offset : 0.41 in
- Pad Thickness : 0.12 in
- Wire Strip Length : 1-7/16 in
- Barrel Style : Chamfered
- Tongue Angle : Straight
- Voltage Rating : 600 VAC to 35 kV
|
-
Line Drawing
https://econtent.adhq.com/dam/Original/396/IDW_DOCUMENT_a6735837d231d07e57bbd17bd304d5a0d69b3980fab4a4e488452bbfc1ebc3cd.pdf
-
Specification Sheet
https://econtent.adhq.com/dam/Original/782/IDW_DOCUMENT_1412143c3dce750c9e164fc3bf60937b7e371b55c41488c5d395a415056aa995.pdf
-
Catalog
https://econtent.adhq.com/dam/Original/782/IDW_DOCUMENT_226aa6003846444e01889ae7eb136d7415173afb5cb42ac112596ab3037f30ba.pdf
