BURNDY® YAZ25TC38 1092770

BURNDY®

1-Hole Copper Compression Lug

  • loading
  • Manufacturer: HUBBELL
  • Brand Name: BURNDY®
  • PN: YAZ25TC38
  • PN: YAZ25TC38
  • UPC: 78181023988
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Qty
  • loading

BURNDY® HYLUG™ 1-Hole Copper Compression Lug with Inspection Hole, Long Barrel, 2 AWG Conductor, 5/16 in Stud, Brown Color Code

  • Manufacturer: HUBBELL
  • Brand: BURNDY®
  • PN: YAZ25TC38
  • CX SKU: 1092770
  • UPC: 78181023988
  • Type: Compression Lug
  • Number of Holes: 1
  • Barrel Type: Long
  • Inspection Hole: Yes
  • Conductor Size: 2 AWG
  • Color Code: Brown
  • Die Code: 10
  • Stud Size : 5/16 in
  • Stud Hole Diameter : 0.40 in
  • Outside Diameter : 0.51 in
  • Barrel Length : 1.25 in
  • Pad Width : 0.60 in
  • Overall Length : 2.27 in
  • Hole Offset : 0.41 in
  • Pad Thickness : 0.12 in
  • Wire Strip Length : 1-5/16 in
  • Barrel Style : Chamfered/Skived
  • Tongue Angle : Straight
  • Voltage Rating : 600 VAC to 35 kV
  • pdfLine Drawing https://econtent.adhq.com/dam/Original/105/IDW_DOCUMENT_363c0aa939454aa422086b41209a95247ec30f52ef4ad426d455741a134de179.pdf
  • pdfSpecification Sheet https://econtent.adhq.com/dam/Original/127/IDW_DOCUMENT_6113072ec3152adcfebba0c5c2a1e0462af6777fd3d47ced6fd46b782905fb3c.pdf
  • pdfCatalog https://econtent.adhq.com/dam/Original/193/IDW_DOCUMENT_1bc0b21a5f51c364f01c4fce7f512670eb8df4c3c673c0ff68cd3c4d90c77b71.pdf
