Square D™ Molded Case Circuit Breaker, B-Frame, PowerPact™ Series, 3 Pole, 35 A, 600Y/347 VAC, 14 kA, Thermal Magnetic Trip, 400 A Hold, 600 A Trip, Line/Load Lug Connection, 14 to 2/0 AWG Al/Cu Wire, I-Line Mount, 5.39 in H x 3.19 in W x 3.5 in D
- The new generation PowerPact with Micrologic circuit breakers set the standard with direct access to energy management
- Integrated metering enhances their protective functions. For the first time, Schneider Electric™ users can monitor energy from 15 to 3000 A, offering new performance in a remarkably compact device
- Devices with the Micrologic electronic trip unit provide adjustable protection settings for greater system flexibility
- In addition to electronic protection, Micrologic trip units allow users to monitor both energy and power
- Through direct access to in-depth information and networking using open protocols, PowerPact circuit breakers with Micrologic trip units let operators optimize the management of their electrical install
Standards
CSA
CCC
CE
UL Listed
IEC
-
Manufacturer: Schneider Electric
-
Brand: Square D™
-
PN: BDA36035
-
CX SKU: 1022064
-
UPC: 785901051244
- Type: Molded Case Circuit Breaker
- Series: PowerPact™
- Frame: B
- Number of Poles: 3
- Amperage Rating: 35 A
- Voltage Rating: 600Y/347 VAC
- Interrupt Rating: 14 kA
- Trip Type : Thermal Magnetic
- Trip Range : 400 A Hold, 600 A Trip
- Connection Type : Line/Load Lug
- Wire Size : 14 to 2/0 AWG Al/Cu
- Mounting Type : I-Line
- Dimensions : 5.39 in H x 3.19 in W x 3.5 in D
|
