Square D™ QBA32200 920281

Square D™

PowerPact™ Q-Frame Molded Case Circuit Breaker

  • loading
  • Manufacturer: Schneider Electric
  • Brand Name: Square D™
  • PN: QBA32200
  • PN: QBA32200
  • UPC: 785901702948
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Qty
  • loading

Square D™ Molded Case Circuit Breaker, Q-Frame, PowerPact™ Series, 3 Pole, 200 A, 240 VAC, 10 kA, Thermal Magnetic Trip, 1200 A Hold, 2400 A Trip, I-Line® Lug Connection, 4 AWG to 300 MCM Al/Cu Wire, I-Line Mount, 6.47 in H x 4.5 in W x 3.93 in D

  • Provides Overload and Short Circuit Protection
  • Voltage Rating of 240V AC.
  • Interrupt Current Rating of 10 kA at 240V.
  • Features Long Time/Instantaneous Functionality
  • Used in Power Distribution System
  • UL Listed and CSA Certified
  • Manufacturer: Schneider Electric
  • Brand: Square D™
  • PN: QBA32200
  • CX SKU: 920281
  • UPC: 785901702948
  • Type: Molded Case Circuit Breaker
  • Series: PowerPact™
  • Frame: Q
  • Number of Poles: 3
  • Amperage Rating: 200 A
  • Voltage Rating: 240 VAC
  • Interrupt Rating: 10 kA
  • Trip Type : Thermal Magnetic
  • Trip Range : 1200 A Hold, 2400 A Trip
  • Connection Type : I-Line® Lug
  • Wire Size : 4 AWG to 300 MCM Al/Cu
  • Mounting Type : I-Line
  • Dimensions : 6.47 in H x 4.5 in W x 3.93 in D
