Hubbell Wiring Device-Kellems HBL5266CA | Connexion
Hubbell Wiring Device-Kellems HBL5266CA 882334

Hubbell Wiring Device-Kellems

15A 125V, NEMA 5-15 Industrial Plugs & Connectors

  • loading
  • Manufacturer: HUBBELL
  • Brand Name: Hubbell Wiring Device-Kellems
  • PN: HBL5266CA
  • PN: HBL5266CA
  • UPC: 783585173054
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Qty
  • loading

Wiring Device-Kellems Insulgrip® Straight Blade Plug, Grounding Standard, 125 VAC, 15 A, 0.5 hp, 2 Pole, 3 Wires, NEMA 5-15P, Commercial/Industrial Grade, IP20 Enclosure, 0.325 to 0.655 in Diameter Cord, -40 to 75 deg C, Threaded Terminal, Composite, Black/White, 2.11 in L x 1.53 in W x 1.22 in H

  • 8-Position angled plug
  • Low profile
  • Roomy wiring chamber provides ample space for wiring

  • Manufacturer: HUBBELL
  • Brand: Hubbell Wiring Device-Kellems
  • PN: HBL5266CA
  • CX SKU: 882334
  • UPC: 783585173054
  • Type: Straight Blade Angle Plug
  • NEMA Rating: 5-15P
  • Voltage Rating: 125 VAC
  • Amperage Rating: 15 A
  • Horsepower: 0.5 hp
  • Number of Poles: 2
  • Number of Wires: 3
  • Grade : Industrial/Commercial
  • Cord Diameter : 0.325 to 0.655 in
  • Temperature Rating : -40 to 75 deg C
  • Terminal Type : Screw
  • Material : Nylon
  • Color : Black
  • Dimensions : 2.11 in L x 1.53 in W x 1.22 in D
  • pdfSpecification Sheet https://www.cxconnect.com//ASSETS/DOCUMENTS/ITEMS/EN/WIRING_HBL5266CA_spec.pdf
