Milbank® Ringless Multi-Position Meter Socket With Horn Bypass, 4 Jaw, 3 Position, 300 VAC, 200 A, 1 Phase, 60 Hz, Overhead/Underground Feed, 4 AWG to 600 MCM Wire, Large Closing Plate, Single Mechanical Terminal, NEMA 3R Enclosure, Glass Polyester Insulation, Galvanized Steel, Powder Coat Finish, 34-2/4 in W x 5-1/8 in D x 14 in H
-
Manufacturer: Milbank Manufacturing
-
Brand: Milbank®
-
PN: U1253-X-KK-K3-PED
-
CX SKU: 163998
-
UPC: 784572133532
- Type: Ringless Multi-Position Meter Socket
- Number of Jaws: 4
- Number of Positions: 3
- Voltage Rating: 300 VAC
- Amperage Rating: 200 A
- Phase: 1
- Bypass Type: Horn
- Frequency Rating : 60 Hz
- Feed Type : Overhead/Underground
- Wire Size : 4 AWG to 600 MCM
- Main Breaker Size : No Main Breaker
- Hub/Closing Plate : Large Closing Plate
- Mounting Type : Surface
- Enclosure Rating : NEMA 3R
- Terminal Type : Single Mechanical
- Equipment Ground : Ground Lug
- Insulation : Glass Polyester
- Material : Galvanized Steel
- Finish : Powder Coat
|
-
Specification Sheet
https://www.cxconnect.com//ASSETS/DOCUMENTS/ITEMS/EN/Milbank_U1253_X_KK_K3_PED_Datasheet.pdf
